OZ-DH-H1 STD SSS - HYDRAULIC DOOR HINGES
The OZ-DH-H1 STD SSS Hydraulic Door Hinge is a precision-engineered, spring-loaded hinge designed for double-action glass doors. Suitable for doors up to 1000 x 2200 mm with a maximum weight of 100 kg and glass thickness of 8–12 mm, it provides smooth, controlled operation with adjustable opening and closing speeds. Available with 90° hold-open or no hold-open options, it delivers reliable performance, consistent door control, and durability for commercial and high-traffic installations.
- Application: Double-action glass doors.
- Glass Thickness: Supports 8–12 mm thick glass panels
- Maximum Door Width: 1000 x 2200 mm
- Material: Satin Stainless Steel (SSS)
- Rotation & Functionality: 90° hold-open or no hold-open
- Unit of Measure: PC
The OZ-DH-H1 STD SSS Hydraulic Door Hinge is a high-performance, spring-loaded hinge designed specifically for double-action glass doors in commercial, retail, and high-traffic environments. Engineered for reliability and precision, it ensures smooth, controlled door movement while maintaining consistent functionality over prolonged use.
This hinge accommodates doors up to 1000 x 2200 mm in size, with a maximum weight of 100 kg (220 lbs) and glass thickness between 8–12 mm, making it suitable for a wide range of frameless or semi-frameless glass door systems. Its adjustable opening and closing speeds provide fine control over door movement, enhancing user safety and operational efficiency.
The OZ-DH-H1 offers flexibility with 90° hold-open and no hold-open options, allowing it to meet diverse design and operational requirements. Built from high-quality Satin Stainless Steel (SSS), the hinge provides excellent corrosion resistance, durability, and a professional aesthetic that complements modern architectural glass installations.
